Pivot True V400 4" Adjustable Set Hinge. Finish: Oil Rubbed Bronze. Set hinge adjusts the door vertically. Commonly used on Jeld-Wen doors and others.
Minimum of 1 set hinge per door needed. Also 2 Guide hinges (horizontial adjustment) needed per door.
KEY FEATURES
Seamlessly retrofits a 4" X 4" one-step pocket route with 5/8" corner radius.
Hex head adjustment screws, not Phillips or Slotted, to provide secure tool engagement and prevent stripping during adjustment.
Screw hole locations optimized away from panel edge to prevent accidental wood splitting.
Panel leaf incorporates a unique shield to keep out debris and provide a premium • appearance in the closed position.
Incorporates Teflon filled bushings for increased wear resistance.
Non-removable pin (NRP) option available for secure out-swing applications.
PERFORMANCE AND OPERATION
The Set Hinge Adjusts 1/4" vertically and the Guide Hinge adjusts 3/16" horizontally.
Easily reversible for either left or right-hand hinge applications.
Innovative, patent-pending adjustment mechanism achieves extremely low adjustment torque with a standard 3/32" hex wrench.
Exceeds BHMA – grade 3 standards for wood, vinyl, aluminum and steel doors.
***Special order, allow 1-2 weeks before shipping.
