Pivot True V400 adjustable guide hinge. Finish: Brushed Chrome. 4" x 4" Adjustable door hinge. Guide hinge adjusts the door horizontally. Minimum of 2 per door needed.
There are two types of adjustable door hinges for each door panel.
A. Set Hinge: One per panel. This has vertical adjustment. Our 56-126 (sold separately).
B. Guide Hinge: Minimum of two per panel. These hinges only have the horizontal adjustment. Our 56-125.
***Special order, non-returnable. Allow 1 to 2 weeks to ship.
Key Features:
Seamlessly retrofits a 4" X 4" one-step pocket route with 5/8" corner radius.
Hex head adjustment screws, not Phillips or Slotted, to provide secure tool engagement and prevent stripping during adjustment.
Screw hole locations optimized away from panel edge to prevent accidental wood splitting.
Panel leaf incorporates a unique shield to keep out debris and provide a premium appearance in the closed position.
Incorporates Teflon filled bushings for increased wear resistance.
Non-removable pin (NRP) option available for secure out-swing applications.
Performance and Operation:
Adjusts 1/4" vertically and 3/16" horizontally.
Easily reversible for either left or right-hand hinge applications.
Innovative, patent-pending adjustment mechanism achieves extremely low adjustment • torque with a standard 3/32" hex wrench.
Exceeds BHMA – grade 3 standards for wood, vinyl, aluminum and steel doors.
